Mitutoyo 125-115 Screw Thread Micrometer, 50 to 75 mm, 5.5 to 7 mm/4,5-3,5TPI

Description

The Mitutoyo 125-115 Screw Thread Micrometer is an analog measuring tool designed to directly measure the pitch diameter of 60° V-threads, eliminating the need for complex calculations. It is equipped with a 60° conical spindle and a fixed V-anvil.

Key features

• 60° conical spindle and V-anvil: Allows for direct measurement of the screw pitch diameter without the need for additional calculations.
• Carbide-tipped measuring faces: Enhances durability and wear resistance, ensuring long-term accuracy.
• Ratchet stop mechanism: Provides a constant and repeatable measuring force, ensuring uniform pressure is applied for consistent measurements.
• Spindle lock: Secures the spindle in place to hold a measurement, preventing accidental changes while reading the scale.
• Zero-point adjustment standard bar: Included for the 50–75 mm range to ensure precise zero-point calibration.
• Satin chrome finish: The thimble and sleeve are finished with satin chrome, making the scales easier to read and reducing glare.
• Durable frame: The frame is coated with a baked enamel finish to resist wear and prolong the tool's lifespan.
• Fitted case: The micrometer comes with a plastic case for secure storage and protection.
