Mitutoyo 125-114 Screw Thread Micrometer, 25 to 50 mm, 2 to 3 mm/13-9TPI

Description

The Mitutoyo 125-114 Screw Thread Micrometer is an analog mechanical micrometer from the Series 125, used to measure the pitch diameter of metric and unified screw threads. This model features a fixed 60-degree V-anvil and a conical spindle tip. The specified range for the requested model is 25 to 50 mm, with graduations of 0.01 mm, and it is suitable for threads with a 2 to 3 mm pitch or 13 to 9 TPI.

Key features

• Direct measurement: The fixed anvil and conical spindle allow for direct measurement of the screw thread's pitch diameter without the need for calculations.
• Constant force: The ratchet stop mechanism ensures that measurements are consistently applied with a uniform force, providing precise and repeatable readings.
• Durable construction: The frame has a baked enamel finish for improved durability and a long lifespan. The measuring faces are constructed of hardened steel.
• Easy to read: The satin chrome finish and laser-etched markings on the thimble and sleeve provide high visibility and easier reading.
• Included accessories : The micrometer comes with a fitted plastic case for protection and storage.
