Mitutoyo 125-112 Screw Thread Micrometer, 25 to 50 mm, 0.4 to 0.5 mm/64-48TPI

Description

The Mitutoyo 125-112 Screw Thread Micrometer is an analog measuring tool designed to precisely measure the pitch diameter of 60° metric or unified screw threads. Unlike other models in the Series 125, which are often sold with a specific thread range, the 125-112 designation corresponds to a 25–50 mm measuring range for threads between 0.4 and 0.5 mm pitch, or 64–48 threads per inch (TPI).

Key features

• Measurement: Measures the pitch diameter of screw threads, displaying the reading directly with no need for calculations.

• Thread range: For the 25–50 mm measuring range, it is compatible with metric threads from 0.4 to 0.5 mm and unified threads from 64 to 48 TPI.

• Constant force: A ratchet stop mechanism provides a constant measuring force to ensure consistent and accurate measurements.

• High-durability construction:
  Features a satin chrome finish on the thimble and sleeve for easy reading.
  Includes a durable, baked-enamel finish on the frame for longevity.

• Zero-point adjustment: A standard bar is included for setting the zero point accurately.

• Analog display: The micrometer features an analog, vernier scale.
  Storage: Comes in a fitted plastic case for protection.
