Sanwa DCM660R True RMS Clamp Meter for Electrical and HVAC Work + DMM Functions

Description

The Sanwa DCM660R is a True RMS clamp meter designed for electrical and HVAC professionals, combining the functionality of both a clamp meter and a digital multimeter (DMM). Its True RMS capability ensures accurate measurements for both standard and distorted electrical waveforms.

Key Features

True RMS: This feature allows for accurate measurements on non-sinusoidal waveforms, such as those found in variable speed drives and other electronics.

DMM functions: The device includes test leads for performing standard multimeter functions, such as voltage and resistance tests.

Large backlit LCD: The 6600-count digital display has a backlight for easy reading in dark or poorly lit environments.

Hold functions:

     1. Data Hold: Freezes the current reading on the display for convenient reference.

     2. Max/Min Hold: Captures and displays the maximum and minimum values detected during a measurement session.

Auto Power Save: To conserve battery life, the meter automatically turns off after 15 minutes of inactivity. This feature is non-cancellable on this model.

Safety rating: The DCM660R is safety compliant with the IEC61010-1 standard and rated for CAT III 600V environments.
